Witam serdecznie wszystkich forumowiczów. Mam pytanie dotyczące mojej płyty głównej, a mianowicie, czy procesor quad q6600 2,4 pójdzie na tej płycie głównej?
Moim starym e5200 już niewiele mogę zdziałać, natomiast kolega ma na stanie właśnie q6600, którego nie używa.
płyta to MS-7502 (tak wiem, w processor support nie ma quadów, ale to dlatego, że są one młodsze od płyty)
http://ark.intel.com/pl/products/29765/Intel-Core2-Quad-Processor-Q6600-8M-Cache-2_40-GHz-1066-MHz-FSB
OPIS PŁYTY:
Processor Support
- Intel® Core 2 Quad/Core 2 Duo/Dual-Core(E2xxx) processors in the
LGA775 package
Supported FSB
- 1333/ 1066/ 800 MHz
Chipset
-
North Bridge: Intel® G33 chipset
-
South Bridge: Intel® ICH9DH chipset
Memory Support
-
DDR2 800/ 667 SDRAM (8GB Max)
-
4 DDR2 DIMMs (240pin / 1.8V)
LAN
- Supports PCIE LAN 10/100 Fast Ethernet by Intel 82562V
Audio
-
Chip integrated by Realtek® ALC888S
-
Flexible 8-channel audio with jack sensing
-
Supports 2 SPDIF-out (coaxial & optical)
-
Compliant with Azalia 1.0 Spec
-
Meet Microsoft Vista Premium spec
SATA
-
6 SATAII ports by ICH9DH
-
Supports storage and data transfers at up to 300 MB/s
1394
- Supports 1394 by VIA VT6308
FDD
-
1 floppy port
-
Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
Connectors
Back panel
-
1 PS/2 mouse port
-
1 PS/2 keyboard port
-
1 Serial port
-
6 USB 2.0 Ports
-
1 1394 port
-
1 LAN jack (10/100)
-
5 flexible audio jacks
-
1 Optical SPDIF-Out port
-
1 Coaxial SPDIF-Out port
On-Board Pinheaders / Connectors
-
3 USB 2.0 pinheaders
-
1 1394 pinheader
-
1 SPDIF-out pinheader
-
1 CD-in connector
-
1 front audio pinheader
-
1 VFD connector
-
1 SCART-Out connector
Slots
-
1 PCI Express x16 slot
-
1 PCI Express x1 slot
-
1 PCI white slot, support 3.3V/ 5V PCI bus Interface, support 1
device
- 1 PCI blue slot, support 3.3V/ 5V PCI bus interface, support 2
devices
Form Factor
- Micro-ATX (24.5cm X 24.5cm)
